Process Meter
APM-PROC-APO
A specialized digital process meter for process control applications
The APM Process Meter is a specialized digital process meter for process control applications including variable speed drives, flow and pressure transducers and linear and non-linear sensors.
Benefits include:
20 point non-linear conversion
Can measure 0-10V DC or 0-50mA
Micro Meter version available for low amperage measurements up to 200uA DC
0.1% accuracy across the input range
| APM Input |
0 – 10V DC, 0 – 50mA |
|---|---|
| PSU |
12 – 24V AC/DC |
| Communication |
Modbus RTU Optional |
| Outputs |
Output 1: Digital (open collector) or Analog (4-20mA), Output 2: Digital (open collector) or Analog (4-20mA) |
| Dimensions |
72mm x 72mm x 53mm |
| Screen Size |
57mm x 53mm |
| Accuracy |
0.1% |
| Certifications |
CE, cUL, IP65, NEMA Type 4 & 12 (UL50), ROHS, UL |
